RABALE · NAVI MUMBAI

Inside Factory W-431

Explore the building, inspect the original plan,
and find the factory on the map.

Explore the factory

Proposed-plan reconstruction · Approximate geometry · Frontage photo: March 2026
Loading the 3D reconstruction…
Drag to orbit · Scroll to zoom · Select a numbered stop

Drawing evidence & reconstruction basis

Original drawing photograph for the selected tour stop

THE ORIGINAL DRAWING

Floor plan & building sections

Open full-resolution image ↗
One large image combining the left and right photographs of the original factory drawing, including the ground-floor plan, first-floor plan, elevations, sections and area statement.
Original photographs IMG_6854 and IMG_6856, combined into one image. The centre join is a side-by-side presentation, not a measured stitch.

VISIT THE FACTORY

431, Road Number 20

T.T.C. Industrial Area, MIDC Industrial Area
Rabale, Navi Mumbai, Maharashtra 400701

View location on Google Maps ↗
